BEVA Welded Sand Gabion®
Flood-Retaining Embankment
SNI 03-3750-1995
BEVA Welded Sand Gabion®
The Right Solution for Flood Mitigation
BEVA Welded Sand Gabion® is a sand gabion consisting of a multicellular series of welded steel wire mesh (JKBL) with a Zinc + 10% Aluminium coating to protect the core wire and make it more resistant to rust. The inside of the sand gabion is lined with anti-UV non-woven geotextile for added durability in the field.
BEVA Welded Sand Gabion® acts as a temporary flood barrier, with a robust and easy-to-use system, this product is a great help for works that require a quick turnaround or emergency response. Without the need for special equipment, BEVA Welded Sand Gabion® is more efficient and durable than other types of products with similar functions.
This product has a load-bearing capacity of 2700 kPa per 1 piece system or equivalent to 135 m of embankment height. When properly installed, the Beva Welded Sand Gabion-based flood defence system can last for over 15 years, making it suitable as an alternative flood defence product. Sand as a filling material is also more readily available locally.
BEVA Welded Sand Gabion® complies with the Indonesian National Standard (SNI) No. 03-3750-1995 and has been certified for the Domestic Component Level (TKDN). Its production processes adhere to ISO 9001:2015, ISO 14001:2018, ISO 45001:2018, and SMK3L standards.
BEVA GABION® offers precision, robust and long-lasting solutions for a wide range of applications in the construction industry. With a combination of advanced technology, high quality materials and SNI certification, BEVA GABION® offers peace of mind and a guarantee of reliability for your projects.
Wire Material
BEVA Welded Sand Gabion® is available in Zinc + Aluminium coated wire. Produced with advanced machinery, certified with SNI-9039:2021 and have high TKDN value.
Main raw materials :
- ZINC + 10% Aluminium
Geotextile Materials
BEVA Welded Sand Gabion® offers two types of geotextile material, non-woven polypropylene and non-woven polyester, which can strengthen the structure of this product.
Main raw materials :
- Geotekstil Non-Woven Polypropylene
- Geotekstil Non-Woven Polyester
Wire Diameter
The diameter of BEVA Welded Sand Gabion® provides a stronger and more durable gabion structure to withstand loads and pressures.
Available in diameter :
- 4.0 mm
Box Size
Each unit of BEVA Welded Sand Gabion® is produced with a size tolerance of 0.10% mesh aperture.
Available sizes length x width x height :
- 4.0 mm X 1.0 mm X 1.0 mm
Mesh Size
Each BEVA Welded Sand Gabion® is precisely manufactured from parallel rows and columns of intersecting wire mesh, welded together for greater tensile strength.
Available sizes width x height :
- 100 mm X 100 mm
An effective and efficient solution for long-term flood management for up to 15 years. With rust-resistant Welded Steel Wire Mesh (JKBL) material and UV-resistant geotextile, it provides strong durability in the field
For further info, please contact us at :
021 – 641 1624
0811 1995 715
sales@bevananda.comFind a wide selection of similar products that can meet your project needs. Providing innovative solutions of the highest quality to ensure the success of every civil engineering and landscape decoration application.
View project detail
Posted on : 08/01/2024
MEMBANGUN SISTEM GERBANG PAGAR OTOMATIS UNTUK EFISIENSI WAKTU & TENAGA
Sistem gerbang pagar otomatis muncul karena adanya kebutuhan dari masyarakat urban dengan karakter memiliki jadwal kegiatan yang padat dan menuntut segala sesuatunya serba cepat. Karena pola hidup yang serba cepat maka peralatan-peralatan yang mereka gunakan untuk kegiatan sehari-hari harus bisa memudahkan pekerjaan mereka, efisiensi tenaga dan dapat mempersingkat waktu. Seperti halnya dengan aktivitas membuka pagar yang harus bisa dilakukan secara otomatis.
Read MoreBEVA Welded Sand Gabion® consists of a multicellular array of Welded Steel Wire Mesh (JKBL) with a rust-resistant Zinc + Aluminium coating.
Rust Resistant
Zinc + 10% Aluminium (6x better than regular galvanised)
100% Local Product
Fully domestically produced, supporting national industry growth
Efficient Installation
Easy to install, saving time and effort
Load Bearing
Able to withstand loads of up to 2,700 kPa per box, equivalent to 135m of embankment height
Reusable
Tidal lid design can be stored and reinstalled supporting the principle of sustainability
Quality Assured
Manufactured in accordance with ISO 9001:2015 standards for Quality Management, SNI certified and has a high TKDN
FLOOD RETAINING WALL
BEVA Welded Sand Gabions® provide flood protection with a robust and easy to use system. BEVA Welded Sand Gabions® are perfect as an alternative flood protection product.
